| 型號Model | YSL-180RC | |||
|
總重量 Drill rig weight(crawler mounted) |
kg | 9500 | ||
|
長x寬x高（運輸狀態） Length × Width × Height (normal) |
mm | 6350×2200×2950 | ||
|
環境溫度 Ambient Temperature Range |
°C | -10～38 | ||
|
名義鉆孔深度 Nominal Drill Depth |
m | 180 | ||
|
鉆孔直徑 Drill Diameter |
mm | 130～320 | ||
|
鉆孔傾角 Drill Hole Angle Range |
度 | -90～-5 | ||
| 鉆桿動力頭Drill head output | ||||
|
輸出轉速 Output Rotation Speed |
低速 Low speed |
rpm | 40/80 | |
|
加速 High speed |
rpm | 70/140 | ||
|
輸出扭矩 Max Output Torque |
N.m | 8500 | ||
| 動力頭給進Stroke of Power Head | ||||
|
行程 Feeding |
mm | 3500 | ||
|
給進力 Thrust Force |
kN | 45 | ||
|
提拔力 Lifting Capacity |
kN | 65 | ||
| 桅桿Mast | ||||
|
滑移行程 Sliding Stroke |
mm | 850 | ||
| 油泵Oil Pump |
電動力 electromotor |
柴動力 diesel |
||
|
大油泵排量 Output volume(big oil pump) |
ml/r | 71 | 63 | |
|
小油泵排量 Output volume(mini oil pump) |
ml/r | 28 | 25 | |
|
中(加速)油泵排量 Output volume(middle pump) |
ml/r | 63 | 50 | |
| 液壓油Hydraulic Oil | L-HM46 | |||
|
油箱容積 Tank Capacity |
L | 220 | ||
|
回油過濾精度（名義） Nominal Filtration Particle Size |
μm | 10 | ||
|
工作溫度 Max. Work Temperature |
°C | 65 | ||
| 動力機Engine drive type Y225S-4+Y250M-4 | 6BTA5.9 | |||
|
功率 Power |
kW | 37+55 | 132 | |
|
轉速 Rotary Speed (Max.) |
rpm | 1500 | 2200 | |
| 履帶底盤Track Chassis Base | PD135 | |||
|
履帶板寬度 Width of Pedrail |
mm | 400 | ||
|
接地比壓 Unit Pressure |
MPa | ＜0.05 | ||
|
爬坡能力 Climb Ability |
度 | ≤20 | ||
| 空氣或泥漿管道規格Air/Mud Hose Size | ||||
|
球閥 Ball Valve |
in | 1+1/2 | ||
|
膠管內徑 Inner Diameter of Hose |
mm | 45 | ||
| 壓絞車(選配件)Winch(for choice) | ||||
|
提升力 Lift Force |
KN | 11 | ||
